Shree bhagwati (1996) is a leader in manufacturing stand alone top label applicator machine for chemical, pharmaceutical, cosmetic, ayurvedic and herbal industry.
Automatic body oil bottle front and back labeling machine our labeling equipment and machineries have involved ourselves in the industrialized and labeling process of different industries like food, cosmetics and pharmaceutical that require large range of labeling machine like round, flat, oval, square, top, security seal as per the requirement. We customized the labeling machine at a very low price as compare to services provided all over the nation.
Automatic body oil bottle front and back labeling machine our self-adhesive sticker labeling machine has its own single synchronize speed control system and flexible multiple drive function provided. The automatic bottle labelling machine has inbuilt automated label length detection systems that eliminates the need for manually feeding and storing of label length data in memory and retrieving the same every time for change of label size & re-starting the machine. This in turn saves valuable time, avoiding machine-down time, and helps to achieve higher production.
The automatic vertical bottle labeling machine is one of the most users friendly machine . The machine incorporated with latest servo or sophisticated micro processor control label dispensing system with most user friendly sensing system for label and product. It is suitable for flat bottles & squarer bottle. This labeller machine is capable for label it up to 300 bottle per minute depending on products diameter and label size. Our model – 60 / 120 /150 /250/ 300/ 400 /600 product per minute depend application and systems.
Our Self-adhesive labeling machine with speed available below:
60 bottle per minute self adhesive labeler machine,120 bottle per minute bottle sticker labelling machine,150 bottle per minute sticker labeling machine,250 bottle per minute high speed bottle label applicator,300 product per minute high speed bottle and jar labelling line,400 product per minute self adhesive sticker labeling machine,600 product per minute self adhesive high speed labeling machine
Automatic flat bottle & jar sticker labelling machine is suited for glass, plastic aluminium, pet bottles of distillery, food, pharmaceutical and cosmetics industries, pharmaceuticals, mineral water, fmcg products and pesticides having bigger label height and length.
Bottle & jar sticker labelling machine can be supplied with optional toughened (tampered) glass or acrylic safety cabinet. Machines having required all basic features as a standard fitment to match the current market needs and also saves cost and time.
| Machine Name | Automatic Front and Back Labeling Machine |
| Model | Servo Based Machine |
| Product | Body Oil Bottle |
| Production Speed Per Minute | Up to 80 bottle per Minute (Speed Depends up on the Size of the Product and label length) |
| Number of Labeling Dispenser | 2 Labeling Dispenser Head |
| Application | Labeling on front and back side of container |
| Labels Requirement | Self Adhesive Sticker Labels in Roll Form having consistence 3 mm gaps between the 2 labels |
| Label Material | Self Adhesive Cromo Paper Labels |
| Label Roll Outer Diameter | Maximum 300 mm |
| Label Core ID | 75 mm |
| Label Dispensing Accuracy | +1 mm |
| Container Holding Unit | Belt Type Spring Based Top Conveyor |
| Working Height | 850 mm (+50 mm) |
| Conveyor Length | 8 Feet |
| Machine Weight | Approx 350 Kgs |
| Machine Dimension | Approx 8 (L) x 7 (W) x 5 (H) – in Feet |
| Transparent Sensor | Extra Cost |
| Silent Feature |
|
| Machine Main Base Frame | Mild Steel or Stainless Steel 304 |
| Machine Coverings | Complete in Stainless Steel 304 |
| Product Contact Parts | Stainless Steel 304 |
| Non Contact Parts | Stainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable) |
| Conveyor Belt | Rubber Belt (Stainless Steel – for heavy products) |
| Conveyor Shafts | Mild Steel with Hard Chrome or Zinc Plating |
| Conveyor Sprockets | Mild Steel or Nylon |
| Bearings | SKF / Niche / Equivalent |
| Plating(Wherever Applicable) | ENP / Zinc / Hard Chrome / Blackening |
| TOP Conveyor Belt | Timing Sponge Belt |
| Guide Rod & Pin | Stainless Steel 304 |
| Dispenser Rollers | Rubber Molded + Aluminum + Knurling Rollers |
| Dispenser Unit Up & Down | Screw Based UP & DOWN Assembly |
