Shree bhagwati (1996) is a leader in manufacturing automatic labeling machine for chemical, pharmaceutical, cosmetic, ayurvedic and herbal industry.

Automatic front, back and top sides labeling machine our top labeling equipment and machinery have involved ourselves in the manufacturing and labeling process of different industries like food, pharmaceutical and cosmetics that require wide range of labeling like round, flat, oval, square, top, security seal as per the requirement. We offer customized labeling at a very low price as compared to services provided all over the country.

Our self-adhesive sticker labeling machine has its own unique single point like synchronized speed control system and flexible multiple drive application provides. The bottle labelling machine has inbuilt automated label length detection systems that eliminates the need for manually feeding and storing of label length data in memory and retrieving the same every time for change of label size & re-starting the labelling machine. This in turn saves valuable time, avoiding machine-down time, and helps achieve higher production.

The automatic vertical bottle label applicator machine is one of the most users friendly. The labeler machine incorporated with latest servo or sophisticated micro processor control label dispensing system with user friendly sensing system for label and product. It is suitable for sticker labeling on flat bottles. It is capability of labeling is up to 300 products per minute depending on products diameter and label size. Our model – 60 / 120 /150 /250/ 300/ 400 /600 product per minute depend application and systems.

Self-adhesive bottle labeling machine with speed available below

60 bottle per minute depend of label and products sizes and shape self adhesive labeler machine
120 bottle per minute depend of label and products sizes and shape bottle sticker labelling machine
150 bottle per minute depend of label and products sizes and shape sticker labeling machine
250 bottle per minute depend of label and products sizes and shape high speed bottle label applicator
300 product pwer minute depend of label and products sizes and shape high speed bottle and jar labelling line
400 product per minute depend of label and products sizes and shape self adhesive sticker labeling machine
600 Product per minute depend of label and products sizes and shape self adhesive high speed labeling machine

The flat bottle & jar sticker labelling machine is suited for glass, plastic aluminium, pet bottles of distillery, food, pharmaceutical and cosmetics industries, pharmaceuticals, mineral water, fmcg products and pesticides having bigger label height and length.

Bottle & jar sticker labelling machine can be supplied with optional toughened (tampered) glass or acrylic safety cabinet. Machines having required all basic features as a standard fitment to match the current market needs and also saves cost and time.

Machine Name	Automatic Front, Back and Top Sides Labeling Machine
Model	Servo Based Machine
Product	Petroleum Jelly Jar
Production Speed Per Minute	Up to 80 Products per Minute (Speed Depends up on the Size of the Product and label length)
Number of Labeling Dispenser	3 Labeling Dispenser Head
Application	Labeling on front, back and top sides of container
Labels Requirement	Self Adhesive Sticker Labels in Roll Form having consistence 3 mm gaps between the 2 labels
Label Material	Self Adhesive Cromo Paper Labels
Label Roll Outer Diameter	Maximum 300 mm
Label Core ID	75 mm
Label Dispensing Accuracy	+1 mm
Container Holding Unit	Belt Type Spring Based Top Conveyor
Working Height	850 mm (+50 mm)
Conveyor Length	8 Feet
Machine Weight	Approx 350 Kgs
Machine Dimension	Approx 8 (L) x 7 (W) x 5 (H) – in Feet
Transparent Sensor	Extra Cost
Salient Features	S.S. 304 construction including main machine frame. Built in product counter. “No Container – No Label” an electronic sensing device avoids wastage of labels. Machine is suitable for round container for wrap around labeling with the help of Change Parts. Easy to change label application height. Top Conveyor to holding product at the time of labeling. Built In A.C. Variable Frequency Drive System. In compliance with cGMP.

MACHINE’S MATERIAL OF CONSTRUCTION

Machine Main Base Frame	Mild Steel or Stainless Steel 304
Machine Coverings	Complete in Stainless Steel 304
Product Contact Parts	Stainless Steel 304
Non Contact Parts	Stainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
Conveyor Belt	Rubber Belt (Stainless Steel – for heavy products)
Conveyor Shafts	Mild Steel with Hard Chrome or Zinc Plating
Conveyor Sprockets	Mild Steel or Nylon
Bearings	SKF / Niche / Equivalent
Plating(Wherever Applicable)	ENP / Zinc / Hard Chrome / Blackening
TOP Conveyor Belt	Timing Sponge Belt
Guide Rod & Pin	Stainless Steel 304
Dispenser Rollers	Rubber Molded + Aluminum + Knurling Rollers
Dispenser Unit Up & Down	Screw Based UP & DOWN Assembly

Label Roll Empty – Machine Stop System with Alarm.
Missing Label in Roll – Machine Stop System with Alarm.
Special Label Sensor for sensing Transparent Film Labels which does not have any sensing mark on it.
Option of Contact Coder, Hot Foil Coder, HP Cartridge Coder and Inkjet Coder with various speed ranges available.
Toughened Glass or Acrylic Safety Cabinet for Machine.
Tower Light showing the machine status / operation.
Colour or Mono Touch Screen with PLC for machine operation and showing various error messages and information on display.
Special Sensing system for checking missing label on product.
Low Compressed Air – Machine Stop with Alarm system for pneumatically o- operated coding system.
Vision System for checking Barcode, presence or absence of Coding or pharma code on labels.
Vision System with OCR system for checking coding on labels.
Online pneumatically operated product rejection system.
Polycarbonate Enclosure in Stainless Steel Profile.
Packing Conveyor.
