Rotary Labeling Machine

SB – Rotary labelers

Unmatched Quality & Speed - 100% Solution to Your Labelling Requisites

The machine is used for full/partial wrap around labeling on different size of container. Vial Labeling Machines are designed for labeling small, difficult to handle, round products such as Vials, ampoules and test tubes. Vial labeling machines are suitable for independent operation and can also be connected with line operation. For different size of round bottle with high speed Application of Vial Labeling Machine / Ampoule Labeling Machine/ Bottle Labelling Machine / Self Adhesive Vial-Bottle Labeling Machine /Automatic Bottle Labeler Machine for Food and Beverages bottle, Pharmaceuticals vials, Cosmetics bottle and jar , Personal care products bottle , agro chemical Agriculture bottle, Pesticides bottle , FMCG bottle and Jar rotary labeler machine available with Shree Bhagwati.

SPECIFICATION OF THE EQUIPMENT MACHINE’S BASICS

MODEL SBSL-120
Machine Name Rotary Labeling Machine
Model Servo and PLC Based Machine
Suitable for Products Pet / Glass/ Plastic / HDPE Bottle
Application Labeling on Straight Surface of Round Bottle
Production Speed Per Minute (depends on bottle’s Size, label’s length and material) Up to 120 Bottles per Minute
Labels Requirement Self Adhesive Sticker Labels in Roll Form having consistence 3 mm gaps between the 2 labels.
Label Material Self Adhesive Paper Labels
Label Roll Outer Diameter Maximum 300 mm
Label Core ID 75 mm
Label Dispensing Accuracy +1 mm (Wrap Around Label : +1.5 mm)
Working Height 860 mm (+/-50 mm)
Conveyor Length 6 Feet
Silent Feature Ø  Starwheel System

Ø  SERVO base technology

Ø  PLC + HMI operated

Ø  Separate motor for individual operation like starwheel, wrapping label, dispenser, conveyor speed

Ø  Separate AC drive for individual operation

Ø  Compact and user friendly Machine

Ø  Wheel type Up-down movement system

Ø  Castor wheel for machine movement.

Ø  No Label Data Input/retrievals require for any Label Size.

Ø  No Change Parts for Product and Label size.

Ø  Virtually Maintenance free machine.

Ø  Easy to change label application height.

Ø  User Friendly Label Placing Adjustments.

Ø  Suitable for On-Line Inkjet and Contact Coding System.

Ø  Built In A.C. Variable Frequency Drive System.



MACHINE’S MATERIAL OF CONSTRUCTION

PARTICULAR SPECIFICATION
Machine Main Base Frame Stainless Steel 304 Pipe Structure
Machine Coverings Complete in Stainless Steel 304
Product Contact Parts Stainless Steel 304
Non Contact Parts Stainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
Conveyor Slat Stainless Steel 304 Slat with Nylon Strips on Side
Conveyor Shafts Mild Steel with Hard Chrome or Zinc Plating
Conveyor Sprockets Mild Steel or Nylon
Bearings SKF / Niche / Equivalent
Plating(Wherever Applicable) Zinc / Hard Chrome / Blackening
Guide Rod & Pin Stainless Steel 304
Dispenser Rollers Rubber Molded + Aluminum + Knurling Rollers
Dispenser Unit Up & Down Screw Based UP & DOWN Assembly
